Pivot.PivotRows Property (ExPivot)

The PivotRows property specifies the list of columns that builds the first column in the control's list. The LockRowsColumn property specifies whether the first column is locked or unlocked. By lock a row or a column it means that the position of it remains unchanged when the user scrolls the control's content. Use the Layout property to save or restore the control's view once the user closes/runs the application. The DataColumns collection holds the collection of Column objects that specifies the control's data. The FormatConditionalAppearances helps you to provide conditional-format for your data, or in other words, ability to highlight values that matches a specified expression.

The PivotRows in BNF notation is:

PivotRows ::= "<Column>[,<Column>]"
Column ::= <Index>[:<Order>][<Options>]
Index ::= <Digit>[<Digit>]
Digit ::= 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9
Order ::= A | D
Options ::= \[<Option> | ,<Option>\]
Option ::= <CheckOption> | content=<RadioOption>

where

Index, is the index of the Column, a value between 0 and DataColumns.Count - 1
CheckOption is any Key in the FormatAppearances collection
RadioOption is any Key in the FormatContents collection

The control can load data using one of the following methods:

Import method, loads data from a CSV file or from specified text.
DataSource property, assigns an ADO/DAO record set to be loaded.
LoadXML method, loads an XML file previously saved using the SaveXML method
The user can drag and drop any TXT or XML files to the control.

Once the data is loaded to the control, the user can drag and drop columns to summarize the data or set the following properties in the following order:

PivotRows property, specifies the list of columns that determines the first column in the control's list
PivotColumns property, specifies the list of columns that determines the rest of the columns in the control's list
PivotTotals property, specifies the list of aggregate functions to be displayed in the control's list

The following screen shot shows the first column in the control's list, that's specified by the PivotRows property:

		Type	Description
		String	A String expression that indicates the list of columns that builds the first column / group-by column in the control's list. The column is identified by its index, and it can be followed by A or D character, which indicates Ascending or Descending sorting order. The , (comma character) may divide multiple columns in the list. For instance, the "0,1:D[bold]" indicates that the Group-By columns are 0 and 1, and the 1 is in descending order displayed in bold. If A is missing, the default sorting order is ascending.
