property Chart.MarkSelectDateColor as Color
Retrieves or sets a value that indicates the color to mark the selected date in the chart.

 TypeDescription
   Color A Color expression that indicates the color being used to highlight the selected dates. The last 7 bits in the high significant byte of the color indicates the identifier of the skin being used to display the selected dates. Use the Add method to add new skins to the control.
The MarkSelectDateColor property specifies the color being used to highlight the selected dates. The AllowSelectDate property specifies whether the user can select a date by clicking the chart's header. The user can select dates by clicking the chart's header. You can select multiple dates keeping the CTRL key and clicking a new date. Use the SelectLevel property to specify the area being highlighted when a date is selected. Use the SelectDate property to select dates programmatically. The SelectedDates property can be used to retrieve all selected dates, or to select a collection of dates. By default, the MarkSelectDateColor is blue ( as your control panel indicates the color for the selected items ). The selected dates are not marked if the MarkSelectDateColor property has the same value as BackColor property in the Chart object. The MarkTodayColor property specifies the color to mark the today date. Use the LevelFromPoint property to get the index of the level from the cursor. Use the DateFromPoint property to retrieve the date from the cursor. The ChartEndChanging(exSelectDate) event notifies your application when the user selects a new date by clicking the header of the chart.

The following screen shot shows the selected dates ( Dec 2 and Dec 4 ) being colored with the default format:

The following screen shot shows the selected dates ( Dec 2 and Dec 4 ) being colored with a solid color (2130771712, 0x7F00FF00):

The following screen shot shows the selected dates ( Dec 2 and Dec 4 ) being colored with this EBN file (16777216, 0x1000000):

The following screen show how a new date gets selected once the user clicks a date in the chart's header:

Your application can provide some options to help user while performing moving or resizing the bars at runtime as follow:

The following VB sample shows how you can change the color for selected dates to be solid:
With G2antt1
	.BeginUpdate
	With .Chart
		.FirstVisibleDate = #1/1/2008#
		.MarkTodayColor = .BackColor
		.LevelCount = 2
		.MarkSelectDateColor = &H7FFDF9F4	' The color is actually FDF9F4 as BBGGRR format
		.SelectLevel = 1
		.SelectDate(#1/2/2008#) = True
		.SelectDate(#1/3/2008#) = True
	End With
End With
The following VB.NET sample shows how you can change the color for selected dates to be solid:
With AxG2antt1
	.BeginUpdate
	With .Chart
		.FirstVisibleDate = #1/1/2008#
		.MarkTodayColor = .BackColor
		.LevelCount = 2
		.MarkSelectDateColor = &H7FFDF9F4	' The color is actually FDF9F4 as BBGGRR format
		.SelectLevel = 1
		.SelectDate(#1/2/2008#) = True
		.SelectDate(#1/3/2008#) = True
	End With
End With
The following C++ sample shows how you can change the color for selected dates to be solid:
/*
	Copy and paste the following directives to your header file as
	it defines the namespace 'EXG2ANTTLib' for the library: 'ExG2antt 1.0 Control Library'

	#import <ExG2antt.dll>
	using namespace EXG2ANTTLib;
*/
EXG2ANTTLib::IG2anttPtr spG2antt1 = GetDlgItem(IDC_G2ANTT1)->GetControlUnknown();
spG2antt1->BeginUpdate();
EXG2ANTTLib::IChartPtr var_Chart = spG2antt1->GetChart();
	var_Chart->PutFirstVisibleDate("1/1/2008");
	var_Chart->PutMarkTodayColor(var_Chart->GetBackColor());
	var_Chart->PutLevelCount(2);
	var_Chart->PutMarkSelectDateColor(0x7FFDF9F4);	// The color is actually FDF9F4 as BBGGRR format
	var_Chart->PutSelectLevel(1);
	var_Chart->PutSelectDate("1/2/2008",VARIANT_TRUE);
	var_Chart->PutSelectDate("1/3/2008",VARIANT_TRUE);
The following C# sample shows how you can change the color for selected dates to be solid:
axG2antt1.BeginUpdate();
EXG2ANTTLib.Chart var_Chart = axG2antt1.Chart;
	var_Chart.FirstVisibleDate = "1/1/2008";
	var_Chart.MarkTodayColor = var_Chart.BackColor;
	var_Chart.LevelCount = 2;
	var_Chart.MarkSelectDateColor = 0x7FFDF9F4;	// The color is actually FDF9F4 as BBGGRR format
	var_Chart.SelectLevel = 1;
	var_Chart.set_SelectDate("1/2/2008",true);
	var_Chart.set_SelectDate("1/3/2008",true);
The following VFP sample shows how you can change the color for selected dates to be solid:
with thisform.G2antt1
	.BeginUpdate
	with .Chart
		.FirstVisibleDate = {^2008-1-1}
		.MarkTodayColor = .BackColor
		.LevelCount = 2
		.MarkSelectDateColor = 0x7FFDF9F4;	// The color is actually FDF9F4 as BBGGRR format
		.SelectLevel = 1
		.SelectDate({^2008-1-2}) = .T.
		.SelectDate({^2008-1-3}) = .T.
	endwith
endwith
